What is a pneumatic cylinder?

What is a pneumatic cylinder?

A pneumatic cylinder, also known as an air cylinder, is a mechanical device that converts compressed air power into linear motion. It is a vital component of pneumatic systems, which use compressed air to transmit and control energy. Pneumatic cylinders are commonly used in various industrial applications for tasks such as lifting, pushing, pulling, and moving objects.

The basic construction of a pneumatic cylinder consists of a cylindrical barrel, a piston, and end caps. The barrel is typically made of metal and houses the piston assembly. The piston divides the cylinder into two chambers: the rod side and the cap side. Compressed air is supplied to one side of the piston, creating pressure that drives the piston and generates linear motion.

Get A Quote

Why Choose Us?

Equipment professional

Our company took the lead and passed the ISO9001 quality system certification. The company specializes in cooperating with State Grid, South Grid, high and low voltage electrical equipment, and supporting services

Business philosophy

The company has always adhered to the "quality" for survival, reputation, as the leading business philosophy, has an excellent team of engineers, perfect production equipment and after-sales service.

After sales service and technical assistance

With perfect after-sales service and technical assistance services, the company can provide after-sales service and technical support according to customer requirements and needs, and respond in the shortest time.

Efficient production efficiency

The machine ensures the maximum utilization of raw materials, improves the efficiency of the production line, and improves the stability of the customer's products.

about us

We Have The Best Solutions for Your Business

Chongqing Xinsheng Technology Electric Co., Ltd. was founded in 2002 and is located in Chongqing, China, one of the four major municipalities in China.

It is a high-tech company engaged in the research, development, production and sales of pneumatic, air cylinder, high and low voltage electrical, outdoor vacuum circuit breakers, indoor high voltage vacuum circuit breakers, indoor high voltage isolation switches, stainless steel photovoltaic distribution boxes, furniture and household appliances and other products. Technology industry company, its products are widely used in power transmission and distribution, machinery, metallurgy, hydropower, petrochemical, mining, transportation, construction, urban and rural power grid transformation and other power grid home appliance construction projects.

Read More
Featured Products

Collection about Us

User Reviews

What users say about Us

The quality is very reliable, looking forward to the next purchase.


Very impressed with the quality of the sample, and the communication. We have placed a production order as a result.


I was shocked when I received the product, the quality is very good, very practical and meets my requirements.


The communication with the supplier was very pleasant and the product provided was very good as I asked, so I placed the order

Frequently Asked Question

Do you have any question?

Pneumatic cylinders offer several advantages, including simplicity of design, reliability, cost-effectiveness, and smooth operation. They are easy to install and maintain, provide precise linear motion, and can handle a wide range of loads. Pneumatic systems are also considered safe as they use compressed air, which is non-toxic and non-flammable.

When selecting a pneumatic cylinder, consider factors such as the required force, stroke length, operating pressure, and the size and weight of the load. Bore size and rod diameter are crucial specifications to match with the application's requirements. Consulting with pneumatic cylinder suppliers or experts can help in determining the most suitable cylinder for your specific application.

Single-acting cylinders have air pressure applied to only one side of the piston, which generates force in one direction. The return stroke is usually achieved by a spring or other external force. In contrast, double-acting cylinders have air pressure applied on both sides of the piston, enabling bidirectional motion without the need for external forces. Double-acting cylinders provide more flexibility in controlling the direction of motion.

Regular maintenance is essential for the optimal performance and longevity of pneumatic cylinders. This includes lubricating the cylinder according to the manufacturer's guidelines, ensuring clean and dry compressed air supply, and periodically checking for leaks, wear, or damage. It is also crucial to use proper filtration and pressure regulation to protect the cylinder and other pneumatic components.
