Construction and working principle

The basic structure of VCB includes vacuum bottle, contacts, control mechanism and arc extinguishing chamber. The vacuum bottle is a sealed container filled with vacuum, which can effectively prevent the generation of arc. Contacts are usually made of copper or silver and are capable of withstanding high voltages and currents. When a fault occurs, the control mechanism operates the VCB to separate the contacts, thereby cutting off the circuit.

Advantages and Features of VCB

VCBs have many advantages over other types of circuit breakers. First, due to the vacuum break, the VCB can reliably cut off high voltages and currents without generating harmful gases or by-products. Second, VCB has a long service life and low maintenance requirements, saving operating costs. In addition, VCB is installed indoors and is suitable for various environments.

Working process of vacuum circuit breaker

When a fault occurs, the VCB generates an arc through the separation contacts. This arc is directed to an arc chute where it is controlled and eliminated by an arc extinguishing device. The arc extinguishing chamber quickly extinguishes the arc by using technologies such as cooling and deionization, and efficiently converts the arc energy into heat and light energy.

Fields of application and future development

Indoor high-voltage vacuum circuit breakers are widely used in the fields of power generation, transmission and distribution of power systems, as well as industrial and commercial facilities. As power demands grow and technology continues to advance, VCBs continue to evolve in design and functionality. Future development trends will mainly focus on increasing the capacity, reliability and intelligence of circuit breakers to meet changing power demands.
